Range of application:
Swine, ovine, goat, canine and etc.

Features :

Hand-held design, smart and light, easy to carry, convenient for detection.

5" TFT-LCD, wide visual, high brightness, high contrast, image clear and exquisite.

Output: USB2.0, video (PAL-D, NTSC), connecting to video recorder and ultrasonic workstation.

Easy to print out all kinds of detection images and reports.

Optional mouse to operate easier.

Adopted AC and DC to supply power, lithium battery capacity 2600mA which can make machine work more than 180 minutes.

Specifications:
Displayed Depth(mm): 192
Maximal detect depth(mm): ≥140
Resolution(mm): Lateral, ≤4（depth≤80）, ≤5（80＜depth≤130）; Axial, ≤2（depth≤80）
Blind zone(mm): ≤8
Geometric position precision: Horizontal≤20; Vertical≤10
Monitor size: 5.0” TFT-LCD
Display mode: B, B+B, B+M, M, 4B
Image gray scale: 256
Scan depth: 120mm-190mm
Image process: histogram, color encode, gama, image smooth
Measurement: distance, circumference, area, volume, heart rate, gestation age
Notation: date, time, name, sex, age, full screen words edit and etc.
Output: USB 2.0, VIDEO ( PALD, NTSC)

Charging method: adapter, battery

Adapter rating: 100-240V～, 50-60Hz, 70VA

Battery: 2600mAh, continuous work: ≥3 hours

Machine dimension: 230mm(L) x 120mm(W) x 38mm(H)
N.W: 800G

Standard Configuration:

* Scanner Body: 1pc
* Li-ion Battery: 1pc
* 3.5MHz Sector Probe: 1pc
* Charger with a Set of Wires: 1set
* Wrap Bag: 1pc
* Bottle of USG gel: 1pc
* Transportation Case: 1pc
* User Manual: 1pc

Optional:

* 5.0Mhz Waterproof Sector Probe.
* Video Printer
* Li-ion Battery
* Car Charger

* Charging Adaptation Wire
